Western Blot - Anti-4E BP1 Rabbit mAb [17M14K16]

All lanes: R012956 at 1:1,000 dilution

Lane 1: HepG2 (human hepatocellular carcinoma epithelial cell) whole cell lysates

Lane 2: HCT116 (human colorectal cancer epithelial cell) whole cell lysates

Lane 3: SW620 (human colorectal cancer epithelial cell) whole cell lysates

Lane 4: Balb/c mouse heart whole tissue lysates

Lysates/proteins at 10 µg per lane.

Secondary antibody: Goat Anti-Rabbit IgG(H+L), HRP Conjugated (Cat. No. LF102) at 1:5,000 dilution

Predicted band size: 15-20 kDa

Observed band size: 18 kDa

Developed using the ECL technique (Cat. No. SQ201).

Immunohistochemistry - Anti-4E BP1 Rabbit mAb [17M14K16]

Sample: Paraformaldehyde-fixed, paraffin embedded human hepatoma carcinoma tissue

Heat mediated antigen retrieval with Tris-EDTA buffer (pH 9.0) for 30 mins.

Primary antibody: R012956 at 1:200 dilution

Secondary antibody: Goat Anti-Rabbit IgG (H+L), HRP conjugated at 1:1,000 dilution

DAB was used as the chromogen.

Counter stained with hematoxylin.

Positive/negative staining were presented.

Only the secondary antibody was used as the negative control.

Immunohistochemistry - Anti-4E BP1 Rabbit mAb [17M14K16]

Sample: Paraformaldehyde-fixed, paraffin embedded human spleen cancer tissue

Heat mediated antigen retrieval with Tris-EDTA buffer (pH 9.0) for 30 mins.

Primary antibody: R012956 at 1:200 dilution

Secondary antibody: Goat Anti-Rabbit IgG (H+L), HRP conjugated at 1:1,000 dilution

DAB was used as the chromogen.

Counter stained with hematoxylin.

Positive/negative staining were presented.

Only the secondary antibody was used as the negative control.

Immunofluorescence - Anti-4E BP1 Rabbit mAb [17M14K16]

Sample: A431 cells

The cells were fixed with 4% paraformaldehyde (10 min), permeabilized with 0.5% Triton X-100 for 10 minutes and then blocked with 5% BSA in 0.1% PBS-Tween for 0.5 hours.

Primary antibodies: R012956 at 1:100 dilution and α-tubulin Mouse Monoclonal Antibody (Cat. No. LF209) at 1:100 dilution

Secondary antibodies: Goat anti-Rabbit (488) at 1:1,000 dilution (shown in green) and Goat anti-Mouse (555) at 1:1,000 dilution (shown in red)

Nuclei were stained with DAPI (shown in blue).
