Western Blot - Anti-CaMKII alpha Rabbit mAb [40M09K92]

All lanes: R010358 at 1:2,000 dilution

Lane 1: HepG2 (human hepatocellular carcinoma epithelial cell) whole cell lysates

Lane 2: SCC-9 (human tongue squamous carcinoma epithelial cell) whole cell lysates

Lane 3: U2OS (human osteosarcoma epithelial cell) whole cell lysates

Lane 4: SW620 (human colorectal carcinoma epithelial cell) whole cell lysates

Lane 5 :Rat brain whole tissue lysates

Lysates/proteins at 10 µg per lane.

Secondary antibody: Goat Anti-Rabbit IgG(H+L), HRP Conjugated (Cat. No. LF102) at 1:5,000 dilution

Predicted band size: 54 kDa

Observed band size: 54 kDa

Developed using the ECL technique (Cat. No. SQ201).

Immunohistochemistry - Anti-CaMK II alpha Rabbit mAb [40M09K92]

Sample: Paraformaldehyde-fixed, paraffin embedded mouse brrain tissue

Heat mediated antigen retrieval with Tris-EDTA buffer (pH 9.0) for 30 mins.

Primary antibody: R010358 at 1:200 dilution

Secondary antibody: Goat Anti-Rabbit IgG (H+L), HRP conjugated at 1:1,000 dilution

DAB was used as the chromogen.

Counter stained with hematoxylin.

Positive/negative staining were presented.

Only the secondary antibody was used as the negative control.
